DAUMANT PROFIX P-SERIES is a glass fiber-reinforced plastic-nailed insulation anchor developed for the mechanical fixing of thermal insulation boards onto mineral surfaces. Thanks to its plastic nail, it does not create a thermal bridge; it protects the building’s energy performance and minimizes heat loss from the insulation system. It ensures full adhesion with thread systems specially developed for brick (PT), concrete (PB), and aerated concrete (PG) surfaces.
FIELDS OF APPLICATION • Thermal insulation (ETICS/EIFS) systems on residential and mass housing facades, • Fixing of EPS and XPS boards, • Standard-height buildings, • High energy-performance projects where the formation of thermal bridges must be prevented, • Brick, aerated concrete, and fair-faced concrete wall surfaces.
SPECIFICATIONS • Plastic Nail: Glass fiber-reinforced to prevent easy breakage, thermal bridge-free, • Temperature Range: Between −40°C and +80°C, • Full corrosion resistance, • Wide-headed, non-crushing design for insulation boards, • Manufactured from PE raw material (Recyclable), • Complies with ETAG 014 standards.
| INSULATION BOARD THICKNESS | BRICK | CONCRETE | AERATED CONCRETE |
|---|---|---|---|
| 3 cm | 10 cm – 1000 pcs/box | 9.5 cm – 500 pcs/box | 9.5 cm – 500 pcs/box |
| 4 cm | 12 cm – 1000 pcs/box | 11.5 cm – 500 pcs/box | 11.5 cm – 500 pcs/box |
| 5 cm | 12 cm – 1000 pcs/box | 11.5 cm – 500 pcs/box | 11.5 cm – 500 pcs/box |
| 6 cm | 14 cm – 1000 pcs/box | 13.5 cm – 500 pcs/box | 13.5 cm – 500 pcs/box |
| 7 cm | 14 cm – 1000 pcs/box | 13.5 cm – 500 pcs/box | 13.5 cm – 500 pcs/box |
| 8 – 10 cm | 16 cm – 800 pcs/box | 15.5 cm – 400 pcs/box | 15.5 cm – 400 pcs/box |
| INSULATION BOARD THICKNESS | BRICK | CONCRETE | AERATED CONCRETE |
|---|---|---|---|
| 3 cm | 10 cm – 1000 pcs/box | 9.5 cm – 500 pcs/box | 9.5 cm – 500 pcs/box |
| 4 cm | 12 cm – 1000 pcs/box | 11.5 cm – 500 pcs/box | 11.5 cm – 500 pcs/box |
| 5 cm | 12 cm – 1000 pcs/box | 11.5 cm – 500 pcs/box | 11.5 cm – 500 pcs/box |
| 6 cm | 14 cm – 1000 pcs/box | 13.5 cm – 500 pcs/box | 13.5 cm – 500 pcs/box |
| 7 cm | 14 cm – 1000 pcs/box | 13.5 cm – 500 pcs/box | 13.5 cm – 500 pcs/box |
| 8 – 10 cm | 16 cm – 800 pcs/box | 15.5 cm – 400 pcs/box | 15.5 cm – 400 pcs/box |
Instantly find out exactly how much material your project requires!
Simply enter the square meter (m²) of your application area to calculate the total product weight in kilograms, the required number of pieces, and how many pallets they will fit onto all in seconds.
Order the right amount to save both time and budget.
